Identity: Twitter Authentication with React and Asp.NET Identity

Mahdi Karimipour
8 min readAug 19, 2021


End to end guide on how to implement external authentication with Twitter for React apps. It also includes using Asp.NET 5.0 API as the backend, hosted on Azure app service and behind Azure API Manager, along with Asp.NET Identity as it’s Identity backend.

The Need

There are a few ways you could integrate Twitter Authentication with a Single Page Application like React, while relying on your Asp.NET 5.0 API and Asp.NET Identity system.

In this post, I have tried to implement it without using front end components, and rely on my Asp.NET API to orchestrate the entire process, in a way that is repeatable for other Social Logins as well.

I have also used Azure App Services for hosting along with a custom domain, and Azure API Manager to serve the traffic. This in turn added some complexity to the mix, which I will cover in this post as well.

By the way, this topic belongs to the series to set up Authentication and Authorisation for Asp.NET and React ecosystems.

  1. Asp.Net Core Web Api Setup
  2. React Single Page App Setup
  3. Asp.NET Identity DB Setup
  4. Email Sender
  5. Sign Up & Activation
  6. Check User Authentication Status
  7. Change Password
  8. Sign In
  9. Policy Based Access Management
  10. Token Refresh
  11. Google Authentication with React and Asp.NET API
  12. Microsoft Authentication with React and Asp.NET API
  13. Twitter Authentication with React and Asp.NET API


I assume you have your React, Asp.NET API with Asp.NET Identity already set up and in place, and if you haven’t, you can follow the above links to do so.

When I write how-tos, I generally follow the way traffic flows in my application, as it would be easier to understand and follow the whole thing. Based on that, I start with the front end, where user clicks on “Login With Twitter”.

1. Frontend: Login with Twitter

In terms of the end result, as expected, here is my simple auth screen. Please note I am NOT using any frontend Twitter component such as react-twitter-login, as I’d like to give the power to my Asp.NET Identity to manage it.

The code behind this UI is straightforward and is simple HTML and JS. If you’d like to read more on my normal authentication using JWT Bearer token, refer to Sign Up with Pellerex or Sign In with Pellerex. As you can see below, all I have is a simple form, and a submit button.

Notes to consider about the above form:

  • Api Gateway: My Asp.NET API is hosted using Azure App Service, and served via Azure API Manager. By looking at the URL, you see the below fragments:
  • Scheme + Base:
  • Identifying Fragment: /identity
  • Route Versioning: /v1
  • Controller Action: /account/external-login
  • Redirect Uri: This is the address where eventually will be called when user successfully authenticates with Twitter, and get redirected to your API. However this is NOT the first url when user heads back to your API. There is another path which will be called right after a successful auth, and that is by default “signin-twitter”. More on this later

There are some complications with such set up which I will cover later on. In the meantime if you’d like to read more on API Versioning, refer to Route Versioning for Asp.NET 5.0 APIs

Identifying Cookie

Right before our API redirects the user to Twitter, it will create a cookie on your website called “.AspNetCore.Correlation”. When the user gets redirected back to your website, Asp.NET Identity checks for the same cookie to exist, and this is to prevent CSRF attacks. I will get back and talk about this cookie shortly.

2. Backend: External-Login

Next step in our flow is where the user presses the Twitter button, and calls my Asp.NET API “external-login” route, in which I construct the redirect URL, and generate the properties for Twitter Login, returned to my App in the form of a challenge.

3. Twitter Consent Screen

Next if you haven’t configured Twitter to receive the Auth requests, it’s now time toh head over to Twitter Consent Screen Setup and configure it. If you want to publish your own logo to Twitter, and if some other conditions need to be met, Twitter needs to verify your app through a formal process.

4. Twitter Credentials

After that go to the new App Registration, and click on “Certificates and Secrets”, and set up your ClientId (APIKey) and ClientSecret which we need to be able to talk to Twitter APIs. As part of that process, you will also need to set up some Urls, one is the domain for your React app (, and the other is the redirect Url back to your Asp.NET API.

Time Waster Alert

There are two Urls that we set up as Redirect URLs. One is the redirect that we set in Step 2 above, in our API, and the second is the one we set in Step 4 as part of Twitter Credentials Setup process. To help you avoid wasting time, here is how the flow works:

Redirect to Twitter: First your API will initiate the process by sending the user to Twitter.

Twitter Redirect Back: After a successful login, Twitter will redirect the user back to your API, but to an already configured Url by your Asp.NET Identity middleware. That is called Don’t search through your code, as you haven’t set this, and this has been configured by default, I mean the signin-twitter part. The rest of that Url has been configured by us, refer to Step 1 for that.

Middleware Redirects: And finally your middleware will redirect the user back to the callback Url we designated in Step 2:{returnUrl}

Return Url: The return URL you see at the end, that is just for your front end, to send the user back to the screen they were on, before they pressed SignIn button on your website.

Hence, as you can see, what you give Twitter, is the middleware Url, and not the final callback Url in your controller.

Here is how I set those credentials in my application, and for the sake of completeness, I have included my entire Identity Config here:


Configuration, plumbing and troubleshooting your software foundation take a considerable amount of time in your product development. Consider using Pellerex which is a complete foundation for your enterprise software products, providing source-included Identity and Payment functions across UI (React), API (.NET), Pipeline (Azure DevOps) and Infrastructure (Kubernetes).

Exception: Cookie not Found

If like me, you have put your API behind a load balancer or gateway like Azure API Manager, you are now going to hit another challenge. Once user authenticates successfully, on their way back to your API’s middleware (the signin-twitter address), they could face the below 500 error (The page isn’t working. It is currently unable to handle this request).

If you look at the address bar, you would realise it is not set to your custom domain like, but it is set to your Azure Website domain:

The reason behind the exception, and also the behaviour is that Azure Api Manager doesn’t forward some of the headers including the host header, so Twitter would simply redirect to the Url behind the scene (i.e. Azure Websites). If you remember from Step 1, we said there is an identifying cookie set before redirect to Twitter, and that cookie is set to Now when the user gets redirected back to your API, and the host is set to, surely it won’t be able to find the cookie there, and that is the reason behind Cookie Not Found exception.

The fix for this, is to make the API to represent itself as, and you could do it by injecting the below code into your middleware:

5. Callback

Now it is time for our callback route to be called, which is after our middleware callback by Twitter (signin-twitter one).

Consider the below points for the above snippet:

  1. signInManager.GetExternalLoginInfoAsync: What this does is to grab all the arguments in the URL coming back from Twitter, make some other calls back to Twitter to verify the request, and then translate it to user info we are after.
  2. accountService.ExternalLogin: I will cover this in the next section.
  3. Trasnfer the User Tokens to SPA: The other part that needs some attention here, is how to transfer the generated token to be used by your React app. The thing is, this is a call not initiated by your React app, and we need to find a way to transfer the tokens to your React app.
  4. First of all, the approach I have taken regarding external logins, is to rely on them “Just” to authenticate my users. Once done, I will translate that into my own login procedures, and generate my own JWT access and refresh tokens, which will be managed by the Asp.NET APIs.
  5. Knowing that, I generate the JWT tokens, and transfer that to my client using Cookies, as you see in the above snippet. Finally I redirect my user to a page, responsible for reading that Cookie and extracting the JWT tokens to be used by my frontend app.
  6. This is a pretty clean, no hacky, way to manage the Auth flow between React App, and Asp.NET API using Asp.NET Identity as the Identity backend.

6. Manage User Identity

And the last part which is the easiest, is to extract user information, and create or associate the Twitter login, with any already existing profile in our system.

In case you’d like to read more on what’s inside Twitter Auth Manager, refer to Claims Based Auth System using Bearer Token.
